HRCRS-3070

For Enquiry Contact Us

HRCRS-3070

EtherCATFanless Embedded Box PC with 6th Generation Intel® Core i5 Skylake U Processor, M.2 Interface

Features

  6th Generation Intel® Core i5-6200U 2.3 GHz/ Celeron 3955U 2.0GHz
     (Intel® Smart Cache 3 MB)
  Dual LAN 6~10 USB3.0 , 4~6 COM Ports, PS/2
  2 M.2 (M key and E key) and 1 Mini PCIe
  Support -20~70°C Operation Temp
  Support Desktop, VESA and DIN rail mount
  Support EtherCAT Devices Connectivity

Specifications

Model HRCRS-3070-1A1 / HRCRS-3070-2A1 HRCRS-3317R
Processor System CPU Intel® Core i5-6200U                                                           Celeron® Processor 3955U
Frequency Dual-Core 2.3 GHz                                                                   Dual-Core 2.0 GHz
Cache Intel®Smart Cache 3 MB                                                        Intel® Smart Cache 2MB
System Chipset N/A
BIOS UEFI
Memory Technology DDR4 2133 MHz SDRAM
Max. Capacity Onboard 4 GB
Graphics Engine Intel® HD520 Graphics
Display VGA 1, Up to 1920 x 1200
HDMI 1, HDMI 1.4a up to 4096 x 2304
Dual Display VGA + HDMI
I/O Interface USB 4 USB 3.0, 2 USB 2.0           8 USB 3.0, 2 USB 2.0           4 USB 3.0, 2 USB 2.0
Serial Port 3 RS-232/485, 1 RS-232/422/485 5 RS-232/485, 1 RS-232/422/485
Digital I/O 8-pin Digital I/O (DB-9 connector, optional)
Ethernet Controller 2 GbE,10/100/1000 Mbps (Support EtheCAT)
Audio Chipset Realtek ALC269 High Definition Audio (HD)
Connectors Line out
Expansion M.2 Mini PCIe 1 2242 M.key& 1 2230 E.key
1 full-size w/SIM    N/A
1 full-size with SIM
Storage SATA 1 2.5” HDD / SSD, SATA III (Max. data transfer rate 600 MB/s)
mSATA N/A
Power Power Type AT / ATX
Power Supply Voltage 12-28 V DC input (Phoenix Connector), 6.7-1.7 A
Power Adaptor AC-to-DC, 12 V @ 5.4 A, 65 W
Power Consumption (Typical) 2.2A @ 12V (24.35W)    2.2A @ 12V (24.35W) 2.2A @ 12V (24.35W)
Power Consumption 3.18A @ 12V (37.6W)    6.38A @ 12V (71.8W) 3.18A @ 12V (37.6W)
(Max)
Environment Operational -20~70° C (-4~158° F) w/ 2.5” SSD (Humidity: 60° C @ 80% RH Non-condensing)
Non-Operational -40~85° C (-40~185° F) (Humidity: 50° C @ 95% RH Non-condensing)
Vibration 5 Grms, IEC 60068-2-64, random, 5~500 Hz, 1 Oct/min., 1hr/axis, x, y, z 3 axes (w/ SSD only)
1 Grms, IEC 60068-2-64, random, 5~500 Hz, 1 Oct/min., 1hr/axis, x, y, z 3 axes (w/ 2.5” HDD)
Shock 50 G, IEC 60068-2-27, half sine, 11 ms duration (w/ SSD only)
20 G, IEC 60068-2-27, half sine, 11 ms duration (w/ 2.5” HDD)
Certificate EMC CE, FCC Class A
General Dimensions
(W x H x D)
225 x 67.6 x 105 mm (8.86” x 2.66” x 4.13”)
Weight 1.8 kg (3.96 Ib)    1.95kg(4.3lb) 1.8 kg (3.96 lb)
Operation System Windows 7/8/10, WS7E/P, WES8

Applications

  Industrial 4.0/ IoT
  Factory Automation Applications
  Intelligent Factory, Robotic
  Manufacturing Execution System
  Energy Management


HRCRS-3023

For Enquiry Contact Us

HRCRS-3023

Fanless Embedded Box PC with Intel® Celeron® N2930 Processor with Multi-LAN, Mutli-COM

Features

  Intel® Celeron® Processor N2930 (2M Cache, 1.83 GHz)
  Compact Size and Light Weight
  1 SATA HDD/SSD (2.5”), 1 mSATA
  -20~50° C Operating Temperature

Specifications

Model HRCRS-3023-1A1 HRCRS-3023-2A1 HRCRS-3023-3A1
Processor System CPU Intel® Celeron® Processor N2930
Frequency Quad-core up to 1.83 GHz
L2 Cache 2 MB
BIOS UEFI
Memory Technology DDR3L 1066/1333 MHz SDRAM (1.35 V only)
Max. Capacity 8 GB
Socket 1, 204-pin SO-DIMM
Display Graphics Engine Intel® Gen7 HD Graphics
VGA Up to 1920 x 1200
HDMI 2 (1 HDMI, 1 Micro HDMI), supports 1920 x 1200, Max data rate: up to 1.65 Gb/s, HDMI v1.4 up to 1080p
Dual Display VGA, HDMI
I/O Interface USB 1 USB 3.0, 1 USB 2.0
Serial Port 1 COM (RS-232), 1 COM (RS-232/422/485) 1 COM (RS-232), 3 COM (RS-232/422/485) 1 COM (RS-232), 1 COM (RS-232 /422/485)
Speaker Header 1
Ethernet Controller Dual GbE LAN, Intel i210, 10/100/1000 Mbps 4 GbE LAN, Intel i210, 10/100/1000 Mbps
Audio Chipset Realtek ALC662, High Definition Audio (HD)
Connectors (Optional) Line out/ Mic in
Expansion Mini PCIe (Optional) 1 half-size slot / Wi-Fi module 1 full-size slot (USB and mSATA signal) / 3G module 1 half-size
Storage SATA II 2.5” HDD / SSD (Max data transfer rate 3.0 GB/s)
mSATA 1 mSATA shared with full-size Mini PCIe
Power Power Type AT / ATX
Power Supply Voltage Single 12 V DC input
Power Consumption (Typical) 0.72 A @ 12 V (8.64 W)
Power Consumption (Max) 1.38 A @ 12 V (15.8 W)
Power Adaptor AC-to-DC, 12 V @ 5 A, 60 W
Environment Operational -20~60° C (-4~122° F) w/ET RAM & 2.5” SSD
Non-Operational -40~85° C (-40~185° F) w/ 2.5” SSD (Humidity: 60° C @ 80% RH Non-condensing
Vibration 5 Grms, IEC 60068-2-64, random, 5~500 Hz, 1 Oct/min., 1hr/axis, x, y, z 3 axes (w/ SSD )
1 Grms, IEC 60068-2-64, random, 5~500 Hz, 1 Oct/min., 1hr/axis, x, y, z 3 axes (w/ 2.5” HDD)
Shock 50 G, IEC 60068-2-27, half sine, 11 ms duration (w/ SSD only)
20 G, IEC 60068-2-27, half sine, 11 ms duration (w/ 2.5” HDD)
Certificate EMC CE, FCC Class A
General Dimensions (W x H x D) 140 x 42.35 x 116 mm (5.51” x 1.67” x 4.57”)
Weight 0.6 kg (1.32 lb)
Operation System Windows 7/8.1, WES7-E/P, WE8S, Ubuntu 14.04

Applications

  Barcode Scanning
  Embedded Control Systems
  Medical
  Digital Signage
  CIM (Computer Integrated Manufacturing)
