 Rugged Joystick
For Enquiry Contact Us

Rugged Joystick


The 2 axis Hall-type rugged joystick, instrument panel installation method, stainless steel and aluminum alloy materials, spring automatic return structure, German high-precision Hall-type sensor, full temperature range linear correction, IP65 protection level, smoother operation Feel, ergonomic mechanical design. reliable for long life span usage. This joystick is widely used in Defense application, industrial robot, medical equipment, optical instrument, heavy-duty and safety-critical applications.


Button 6
Positioning Spring automatically returns
Operational Angle ± 22.50
Power Supply DC5V, 12-24V (Optional)
Signal Output Analog Voltage, RS232, RS422, USB, CAN(2.0), PWM
Life Span 5 million operating cycles
Material Aluminum, Stainless Steel, Engineering Plastic
Operating Temperature -400C to +700C


 Dual Channel DVI and Audio Recorder
For Enquiry Contact Us

Dual Channel DVI and Audio Recorder


The Rugged Dual DVI Video Recorder is designed for Mission-Critical Applications to address the Recording & Streaming requirements of the Defense & Aerospace market. Suitable for tasks such as post-action analysis, continuous 24/7 surveillance, strategic decision-making, or training purposes. They are built with improved shock and vibration safeguards (MIL-STD-810F) as well as electromagnetic interference protection (MIL-STD-461F).

The VR-0313-280 recorder can be remotely monitored and controlled over Ethernet network.


 2U Height Rugged Computer

Intel® Core™ i5-9500TE, 9M Cache, up to 3.60 GHz
8 GB DDR4-2666 RAM
2 x 1TB solid state hard disk
4 x USB 2.0
  Input Interface DVI x2, 3.5 mm audio jack x2, Support input resolution up to 2048×2160 pixels
  Supports display of signals on the console monitors even when recorder is OFF or not working
  2 x Audio recording channels, Stereo line-in/Stereo balanced inputs with programmable gain. Analog stere line-out for direct pass through of selected input
 Time stamping for Video Frame as well as saved File
 Video Engine: 10-bit video processing, Deinterlace, Cropping, Color Adjustment, Hardware Timestamp, Color Space Conversion, Up/down Conversion, Aspect Ratio Conversion, OSD
 Included Software Capture Express
 230V/115V AC 50/60Hz, Optional 24VDC
 Environmental Specifications:
As per MIL-STD-810F
EMI EMC: As per MIL-STD-461F
